Specifications & options
| MODEL NUMBER | BLADE DIAMETER | AMPS HIGH | CFM HIGH | CFM LOW | TYPE | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| MB-C-30 | 30" | 3.6 | 6300 | 5500 | SWIVEL | 60 |
| MB-RS-C-36 | 36" | 3.6 | 8200 | 7000 | STATIONARY | 70 |
| Blade Diameter | 30"; 36" |
|---|---|
| Amps High | 3.6 |
| Cfm High | 6300; 8200 |
| Cfm Low | 5500; 7000 |
| Type | SWIVEL; STATIONARY |
Source: 2018 catalog, page 59. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Equipment overview
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The catalog lists MB-C-30 through MB-RS-C-36 within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Blade Diameter: 30"; 36"; Amps High: 3.6. These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 1/3 HP, 115V. Confirm which apply to the selected model or optional power package.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Documentation & drawings
Reference: 2018 product catalog, page 59. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
Which models are listed for commercial direct drive blowers?
The catalog records 2 model references for this family. The first listed model is MB-C-30. Compare the model rows and confirm the required configuration when quoting.
How do I choose the right commercial direct drive blowers configuration?
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
Are these current product specifications?
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
