| MODEL NUMBER | MAXIMUM VISCOSITY | MAXIMUM CAPACITY | MAXIMUM HEAD | MAXIMUM S.G. | IMMERSION DEPTH | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| EDP | 400 CPS | 22.75 GPM | 43 FT. | 1.3 | 39" | 20 |
| FHL-PUMP | 500 CPS | 18.5 GPM | 33 FT. | 1.3 | 12" | 21 |
| ODF-PUMP | 500 CPS | 15.9 GPM | 68 FT. | 1.4 | 12" | 21 |
| ABS-PUMP | 600 CPS | 13.5 GPM | 31 FT. | 1.4 | 12" | 18 |
| HCB-PUMP | 500 CPS | 13.5 GPM | 26 FT. | 1.6 | 39" | 35 |
| Maximum Viscosity | 400 CPS; 500 CPS; 600 CPS |
|---|---|
| Maximum Capacity | 22.75 GPM; 18.5 GPM; 15.9 GPM; 13.5 GPM |
| Maximum Head | 43 FT.; 33 FT.; 68 FT.; 31 FT.; 26 FT. |
| Maximum S.G. | 1.3; 1.4; 1.6 |
| Immersion Depth | 39"; 12" |
Source: 2018 catalog, page 319. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Compare the documented dimensions, capacities and model options with the intended application. Include installation, access and operating requirements when requesting a quote.
The catalog lists EDP through HCB-PUMP within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Maximum Viscosity: 400 CPS; 500 CPS; 600 CPS; Maximum Capacity: 22.75 GPM; 18.5 GPM; 15.9 GPM; 13.5 GPM. These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 115V. Confirm which apply to the selected model or optional power package.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 319. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 5 model references for this family. The first listed model is EDP. Compare the model rows and confirm the required configuration when quoting.
Describe the container dimensions, contents and handling operation when selecting a model. Compatibility depends on the particular container and attachment configuration.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
