Open an image to inspect its original detail.
| MODEL NUMBER | PLATFORM SIZE (W x L) | SHELF CLEARANCE | TOP SHELF HEIGHT | MAX CAPACITY CART/SHELF | WEIGHT (POUND) |
|---|---|---|---|---|---|
| DH-PH4-2436-D | 23 13/16" x 35 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 207 |
| DH-PH4-2448-D | 23 13/16" x 47 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 233 |
| DH-PH4-2460-D | 23 13/16" x 59 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 240 |
| DH-PH4-2472-D | 23 13/16" x 71 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 265 |
| DH-PH4-3060-D | 29 13/16" x 59 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 267 |
| DH-PH4-3448-D | 33 13/16" x 47 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 256 |
| DH-PH4-3460-D | 33 13/16" x 59 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 288 |
| DH-PH4-3472-D | 33 13/16" x 71 13/16" | 20¾" | 36 3/16" | 4,000/2,000 lb. | 320 |
| DH-PU2.4-2436-D | 23 13/16" x 35 13/16" | 20¾" | 36 1/8" | 4,000/2,000 lb. | 202 |
| DH-PU2.4-2448-D | 23 13/16" x 47 13/16" | 20¾" | 36 1/8" | 4,000/2,000 lb. | 218 |
| DH-PU2.4-3060-D | 29 13/16" x 59 13/16" | 20¾" | 36 1/8" | 4,000/2,000 lb. | 298 |
| DH-MR2-2436-D | 23 13/16" x 35 13/16" | 20¾" | 36 1/8" | 2,400/2,000 lb. | 225 |
| DH-MR2-2448-D | 23 13/16" x 47 13/16" | 20¾" | 36 1/8" | 2,400/2,000 lb. | 229 |
| DH-MR2-3060-D | 29 13/16" x 59 13/16" | 20¾" | 36 1/8" | 2,400/2,000 lb. | 295 |
| ERGO-FL | OPTIONAL MANUAL FOOT-OPERATED FLOOR LOCK | 6 |
| Platform Size (W X L) | 23 13/16" x 35 13/16"; 23 13/16" x 47 13/16"; 23 13/16" x 59 13/16"; 23 13/16" x 71 13/16"; 29 13/16" x 59 13/16"; 33 13/16" x 47 13/16"; 33 13/16" x 59 13/16"; 33 13/16" x 71 13/16" |
|---|---|
| Shelf Clearance | 20¾"; OPTIONAL MANUAL FOOT-OPERATED FLOOR LOCK |
| Top Shelf Height | 36 3/16"; 36 1/8" |
| Max Capacity Cart/Shelf | 4,000/2,000 lb.; 2,400/2,000 lb. |
Source: 2018 catalog, page 336. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The catalog lists DH-PH4-2436-D through ERGO-FL within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Platform Size (W X L): 23 13/16" x 35 13/16"; 23 13/16" x 47 13/16"; 23 13/16" x 59 13/16"; 23 13/16" x 71 13/16"; 29 13/16" x 59 13/16"; 33 13/16" x 47 13/16"; 33 13/16" x 59 13/16"; 33 13/16" x 71 13/16"; Shelf Clearance: 20¾"; OPTIONAL MANUAL FOOT-OPERATED FLOOR LOCK. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 336. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 15 model references for this family. The first listed model is DH-PH4-2436-D. Compare the model rows and confirm the required configuration when quoting.
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
