SKU 7-13764
GKS Robot 40 Lift Battery powered remote controlled transport system with integrated lift table
Battery powered remote controlled transport system with integrated lift table
- Power source
- Battery powered
- Loading height
- 9.8 inch
Open an image to inspect its original detail.
Specifications & options
| MODEL NUMBER | PLATFORM SIZE (W x L) | UNIFORM CAPACITY | SERVICE RANGE | LIFT SPEED | WEIGHT (POUND) |
|---|---|---|---|---|---|
| SCTAB-400 | 17¾" x 27 5/8" | 400 lb. | 8½" to 28 13/16" | SINGLE | 138 |
| SCTAB-800D | 20" x 35½" | 800 lb. | 15 7/16" to 52" | TWO | 290 |
| SCTAB-500-2033-FP | 20" x 33" | 500 lb. | 6" to 28" | TWO | 263 |
| SCTAB-1000-2040-FP | 20" x 40" | 1,000 lb. | 8" to 32" | TWO | 298 |
| SCTAB-2000-2040-FP | 20" x 40" | 2,000 lb. | 8" to 32" | TWO | 314 |
| SCTAB-2000-3240-FP | 32" x 40" | 2,000 lb. | 8" to 32" | TWO | 379 |
| SCTAB-2000-4242-FP | 42" x 42" | 2,000 lb. | 8" to 32" | TWO | 400 |
| SCTAB-2500-2040-FP | 20" x 40" | 2,500 lb. | 8" to 32" | TWO | 332 |
| SCTABD-750-2040-FP | 20" x 40" | 750 lb. | 7" to 35" | TWO | 291 |
| SCTABD-1000-2033-FP | 20" x 33" | 1,000 lb. | 7" to 35" | TWO | 288 |
| SCTAB-500-2033-DC | 20" x 33" | 500 lb. | 6" to 28" | 4 sec. | 362 |
| SCTAB-1000-2040-DC | 20" x 40" | 1,000 lb. | 8" to 32" | 4 sec. | 402 |
| SCTAB-2000-2040-DC | 20" x 40" | 2,000 lb. | 8" to 32" | 7 sec. | 414 |
| SCTAB-2000-3240-DC | 32" x 40" | 2,000 lb. | 8" to 32" | 7 sec. | 480 |
| SCTAB-2000-4242-DC | 42" x 42" | 2,000 lb. | 8" to 32" | 7 sec. | 502 |
| SCTAB-2500-2040-DC | 20" x 40" | 2,500 lb. | 8" to 32" | 12 sec. | 433 |
| SCTABD-750-2040-DC | 20" x 40" | 750 lb. | 7" to 35" | 4 sec. | 391 |
| SCTABD-1000-2033-DC | 20" x 33" | 1,000 lb. | 7" to 35" | 4 sec. | 388 |
| Platform Size (W X L) | 17¾" x 27 5/8"; 20" x 35½"; 20" x 33"; 20" x 40"; 32" x 40"; 42" x 42" |
|---|---|
| Uniform Capacity | 400 lb.; 800 lb.; 500 lb.; 1,000 lb.; 2,000 lb.; 2,500 lb.; 750 lb. |
| Service Range | 8½" to 28 13/16"; 15 7/16" to 52"; 6" to 28"; 8" to 32"; 7" to 35" |
| Lift Speed | SINGLE; TWO; 4 sec.; 7 sec.; 12 sec. |
Source: 2018 catalog, page 129. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Equipment overview
Start with the load, lifting arrangement and clearance available for the task. Compare each model’s listed operating dimensions and capacity rather than treating the family as one interchangeable configuration.
The catalog lists SCTAB-400 through SCTABD-1000-2033-DC within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Platform Size (W X L): 17¾" x 27 5/8"; 20" x 35½"; 20" x 33"; 20" x 40"; 32" x 40"; 42" x 42"; Uniform Capacity: 400 lb.; 800 lb.; 500 lb.; 1,000 lb.; 2,000 lb.; 2,500 lb.; 750 lb.. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Documentation & drawings
Reference: 2018 product catalog, page 129. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
Which models are listed for foot pump & dc powered scissor lift tables?
The catalog records 18 model references for this family. The first listed model is SCTAB-400. Compare the model rows and confirm the required configuration when quoting.
How do I choose the right foot pump & dc powered scissor lift tables configuration?
Start with the load, lifting arrangement and clearance available for the task. Compare each model’s listed operating dimensions and capacity rather than treating the family as one interchangeable configuration.
Are these current product specifications?
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
