Equipment details
5092EX Explosion Proof Scissor Lift
5092EX Explosion Proof Scissor Lift: Maximum Reach & Capacity for Safe Work in Classified Areas
- Working height
- 56 ft
- Platform dimensions
- 74 x 168 in
Original catalog photograph. Confirm the selected model and configuration with your quote.
Specifications & options
| Ground clearance | 14 in |
|---|---|
| Working height | 59 ft |
| Platform height | 52 ft |
| Capacity | 1,103 lbs |
| Platform length | 13 ft; 19 ft |
| Platform width | 6 ft |
Source: existing product information. Confirm current specifications, supplier-listed approvals and optional configurations with your quote.
PRODUCT INFORMATION
Equipment overview
The HS 5388RT Scissor Lifts comes with 4 Wheel Drive.
Hydraulic differential lock for improved rough terrain capability
14 in ground clearance ensures exceptional rough terrain performance
4 wheel drive
Tight turning radius
Proportional controls for smooth movements
Working height: 59 ft 1 in
Platform height: 52 ft 6 in
Lift capacity: 1,103 lbs
Platform length: 13 ft 1 in
Extended platform length: 19 ft 8 in
Platform extension length: 3 ft 3 in
Platform width: 6 ft 2 in
Storage height: 6 ft 11 in
Height – stowed: 9 ft 10 in
Width: 7 ft 5 in
Length: 13 ft 9 in
Wheelbase: 9 ft
Drive speed: 1 – 3.6 mph
Documentation & drawings
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
What specifications are listed for 12484?
The technical table lists specifications explicitly stated in the existing product information. Confirm the selected configuration and current supplier documentation with your quote.
How do I request a quote for 12484?
Include the product name and SKU 12484, quantity, application, full delivery address and needed-by date. Add required dimensions, load and site constraints where relevant.
Can you confirm freight and delivery timing?
Freight and delivery timing need to be confirmed for the selected configuration, quantity and destination. Include access restrictions and unloading requirements with your quote request.
