HT61 RT PRO Telescopic Boom Lift

Original catalog photograph. Confirm the selected model and configuration with your quote.

Specifications & options

Working height66 ft; 67 ft
Platform height61 ft
Capacity500 lbs

Source: existing product information. Confirm current specifications, supplier-listed approvals and optional configurations with your quote.

PRODUCT INFORMATION

Equipment overview

HT61 RT PRO Telescopic Boom Lift is extremely safe and offers an optimal degree of comfort.

Outstanding performance

66 ft working height

52 ft 1 in maximum outreach

Optimized productivity

Best lifting speed 56s

Fully proportional and simultaneous movements

Reliable safety and comfort

Most rigid boom

Single control for both steering axles

Optimized serviceability

Easy access to all components

Easy boom maintenance

Fully modular basket with upper control box cover and tool tray

Working height: 67 ft

Platform height: 61 ft

Horizontal outreach: 52 ft 5 in

Lift capacity: 500 lbs (2 persons)

Platform size: 8 ft x 3 ft

Length: 29 ft 7 in

Length – storage: 29 ft 7 in

Overall width: 8 ft 1 in

Height – stowed: 8 ft 11 in

Height – storage: 8 ft 11 in

Platform rotation: 175° (+85/-90)

Boom rotation angle: 90° (+75/-15)

Turntable rotation: 360° continuous

Documentation & drawings

Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.

Request model documentation ↗

Questions about this equipment

What specifications are listed for 12504?

The technical table lists specifications explicitly stated in the existing product information. Confirm the selected configuration and current supplier documentation with your quote.

How do I request a quote for 12504?

Include the product name and SKU 12504, quantity, application, full delivery address and needed-by date. Add required dimensions, load and site constraints where relevant.

Can you confirm freight and delivery timing?

Freight and delivery timing need to be confirmed for the selected configuration, quantity and destination. Include access restrictions and unloading requirements with your quote request.
