Low-Profile Scissor Lift Tables — Guardian Series — catalog equipment photograph

Open an image to inspect its original detail.

Low-Profile Scissor Lift Tables — Guardian Series — catalog equipment photographLow-Profile Scissor Lift Tables — Guardian Series — catalog equipment photographLow-Profile Scissor Lift Tables — Guardian Series — catalog equipment photograph

Specifications & options

Model / referenceVERTICAL TRAVELCAPACITYHEIGHT / LOWEREDHEIGHT / RAISEDPLATFORM SIZE / RAISEDBASE FRAME / RAISEDLIFT SPEED (SEC) / RAISED
BM-GLP-1.1K-34R-325530.75"11003.25”34”31.5” x 55”29.5" x 52.75"10
BM-GLP-1.1K-34R-405530.75"11003.25”34”39.5” x 55”29.5" x 52.75"10
BM-GLP-2.2K-34R-325530.75"22003.25”34”31.5” x 55”29.5" x 52.75"18
BM-GLP-2.2K-34R-405530.75"22003.25”34”39.5” x 55”29.5" x 52.75"18
BM-GLP-3.3K-33R-326129.5"33003.25”33”31.5” x 61”29.5" x 52.75"25
BM-GLP-3.3K-33R-406129.5"33003.25”33”39.5” x 61”29.5" x 52.75"25
Documented model configurations6
HEIGHT / LOWERED3.25”
BASE FRAME / RAISED29.5" x 52.75"
Catalog feature / optionUpper platform fitted with safety perimeter which prevents descent on contact
Catalog feature / optionExternal power pack equipped with a relief valve against overloading
Catalog feature / option115 voltage single phase standard
Catalog feature / option230/460 voltage three phase available

Source: 2026 material handling catalog, PDF page 26. Confirm the current selected configuration with your quote.

PRODUCT INFORMATION

Equipment overview

Low-Profile Scissor Lift Tables — Guardian Series is presented here with the configurations documented in the 2026 material handling catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.

Catalog features and options: Upper platform fitted with safety perimeter which prevents descent on contact; Low-tension (24V) control box with up-down buttons; Electric circuit reset button in case the safety perimeter is actuated; External power pack equipped with a relief valve against overloading; Compensated flow valve for controlling lowering speed; External power pack is supplied with 8’ long hoses; Upper limit switch; 115 voltage single phase standard; 230/460 voltage three phase available; Single acting cylinders with drainage system; Check valve to stop the lift table lowering in case of hose burst; Safety clearance between scissors to prevent trapping during operations; Mechanical blocks for safe maintenance operations; Self-lubricating bushings on pivot points; Removable lifting eye(s) to facilitate installation of the lift table Each Selection Can Be Purchased With Hand Or Foot Controls.

Model and option notes: ADD -F FOR FOOT.

Documentation & drawings

Reference: 2026 material handling catalog, PDF page 26. The tables reproduce the documented configurations.

Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.

Request model documentation ↗

Questions about this equipment

How do I choose a model or configuration?

Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.

Are the catalog specifications current?

These specifications come from the 2026 material handling catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.

How do I request a quote?

Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
