Open an image to inspect its original detail.
| MODEL NUMBER | DESCRIPTION | MAXIMUM DUMP ANGLE | MAXIMUM DUMP HEIGHT | UNIFORM CAPACITY | WEIGHT (POUND) |
|---|---|---|---|---|---|
| TCD-M-48-AC | 115V / 1PH | 135° | 48¾" | 400 lb. | 703 |
| TCD-M-48-DC | 12V DC | 135° | 48¾" | 400 lb. | 753 |
| TCD-M-60-AC | 115V / 1PH | 135° | 60 3/8" | 400 lb. | 755 |
| TCD-M-60-DC | 12V DC | 135° | 60 3/8" | 400 lb. | 815 |
| TCD-M-72-AC | 115V / 1PH | 135° | 72 3/8" | 400 lb. | 766 |
| TCD-M-72-DC | 12V DC | 135° | 72 3/8" | 400 lb. | 826 |
| Maximum Dump Angle | 135° |
|---|---|
| Maximum Dump Height | 48¾"; 60 3/8"; 72 3/8" |
| Uniform Capacity | 400 lb. |
Source: 2018 catalog, page 106. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The catalog lists TCD-M-48-AC through TCD-M-72-DC within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Maximum Dump Angle: 135°; Maximum Dump Height: 48¾"; 60 3/8"; 72 3/8". These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 12V. Confirm which apply to the selected model or optional power package.
The catalog entry describes floor-lock positioning, onboard charging. Check the configuration table and quote details to establish which features apply to your selection.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 106. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 6 model references for this family. The first listed model is TCD-M-48-AC. Compare the model rows and confirm the required configuration when quoting.
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
