| MODEL NUMBER | FORK SIZE (W x L) | SERVICE RANGE | CAPACITY 0"-62" RH | CAPACITY 62"-118" RH | WEIGHT (POUND) |
|---|---|---|---|---|---|
| SNM-62-FA | 26¾" x 42" | 2½" to 62" | 2,200 lb. | --- | 1102 |
| SNM15-62-AA* | 8.3" to 26¾" x 42" | 2 1/8" to 62" | 1,500 lb. | --- | 1106 |
| SNM-62-AA | 8.3" to 26¾" x 42" | 2 1/8" to 62" | 2,200 lb. | --- | 1106 |
| SNM-90-AA | 8.3" to 26¾" x 42" | 2 1/8" to 90" | 2,500 lb. | 2,000 lb. | 1502 |
| SNM3-43-AA | 8.3" to 26¾" x 42" | 2 1/8" to 43" | 3,000 lb. | --- | 1380 |
| SNM15-62-FF-27* | 26¾" x 42" | 3 3/8" to 62" | 1,500 lb. | --- | 1221 |
| SNM-62-FF-21 | 21" x 42" | 3 3/8" to 62" | 2,200 lb. | --- | 1170 |
| SNM-62-FF-27 | 26¾" x 42" | 3 3/8" to 62" | 2,200 lb. | --- | 1132 |
| SNM-90-FF-27 | 26¾" x 42" | 3 3/8" to 90" | 2,200 lb. | 1,500 lb. | 1500 |
| SNM3-43-FF-21 | 21" x 42" | 3 3/8" to 43" | 3,000 lb. | --- | 1256 |
| SNM3-43-FF-27 | 26¾" x 42" | 3 3/8" to 43" | 3,000 lb. | --- | 1266 |
| AGM-UPG-2-12V | AGM BATTERY UPGRADE | (2x12V) purchase with new unit | 80 |
| Fork Size (W X L) | 26¾" x 42"; 8.3" to 26¾" x 42"; 21" x 42"; AGM BATTERY UPGRADE |
|---|---|
| Service Range | 2½" to 62"; 2 1/8" to 62"; 2 1/8" to 90"; 2 1/8" to 43"; 3 3/8" to 62"; 3 3/8" to 90"; 3 3/8" to 43" |
| Capacity 0"-62" Rh | 2,200 lb.; 1,500 lb.; 2,500 lb.; 3,000 lb.; (2x12V) purchase with new unit |
| Capacity 62"-118" Rh | ---; 2,000 lb.; 1,500 lb. |
Source: 2018 catalog, page 116. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The catalog lists SNM-62-FA through AGM-UPG-2-12V within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Fork Size (W X L): 26¾" x 42"; 8.3" to 26¾" x 42"; 21" x 42"; AGM BATTERY UPGRADE; Service Range: 2½" to 62"; 2 1/8" to 62"; 2 1/8" to 90"; 2 1/8" to 43"; 3 3/8" to 62"; 3 3/8" to 90"; 3 3/8" to 43". These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 12V. Confirm which apply to the selected model or optional power package.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 116. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 12 model references for this family. The first listed model is SNM-62-FA. Compare the model rows and confirm the required configuration when quoting.
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
