| MODEL NUMBER | UNIFORM CAPACITY | OPERATION | FORK SIZE (W x L) | RAISED HEIGHT | WEIGHT (POUND) |
|---|---|---|---|---|---|
| PMPS-50M | 2,500 lb. | FOOT PUMP | 4" x 36" | 50" | 985 |
| PMPS-50-DC | 4,000 lb. | 12V DC | 4" x 36" | 50" | 1102 |
| PMPS-50-AC | 4,000 lb. | 115V AC | 4" x 36" | 50" | 1081 |
| PMPS-60-DC | 4,000 lb. | 12V DC | 4" x 36" | 60" | 1102 |
| PMPS-60-AC | 4,000 lb. | 115V AC | 4" x 36" | 60" | 1065 |
| LL-PMPS-50-DC* | 1,200 lb. | 12V DC | 4" x 36" | 50" | 911 |
| LL-PMPS-50-AC* | 1,200 lb. | 115V AC | 4" x 36" | 50" | 860 |
| LL-PMPS-60-DC* | 1,200 lb. | 12V DC | 4" x 36" | 60" | 935 |
| LL-PMPS-60-AC* | 1,200 lb. | 115V AC | 4" x 36" | 60" | 875 |
| LL-PMPS-72-DC* | 1,200 lb. | 12V DC | 4" x 36" | 72" | 950 |
| LL-PMPS-72-AC* | 1,200 lb. | 115V AC | 4" x 36" | 72" | 910 |
| PMPS-48FORK | 48" LONG FORKS | (3,200 LB. CAPACITY @ 24" CENTERS) | 200 | ||
| PMPS-PTDS-E | POWER TRACTION DRIVE SYSTEM | 600 | |||
| PMPS-DCR | RETROFIT DRUM CARRIER ROTATOR | (800# cap.) | 239 |
| Uniform Capacity | 2,500 lb.; 4,000 lb.; 1,200 lb.; 48" LONG FORKS |
|---|---|
| Operation | FOOT PUMP; 12V DC; 115V AC; POWER TRACTION DRIVE SYSTEM; RETROFIT DRUM CARRIER ROTATOR |
| Fork Size (W X L) | 4" x 36"; (3,200 LB. CAPACITY @ 24" CENTERS) |
| Raised Height | 50"; 60"; 72"; (800# cap.) |
Source: 2018 catalog, page 113. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The catalog lists PMPS-50M through PMPS-DCR within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Uniform Capacity: 2,500 lb.; 4,000 lb.; 1,200 lb.; 48" LONG FORKS; Operation: FOOT PUMP; 12V DC; 115V AC; POWER TRACTION DRIVE SYSTEM; RETROFIT DRUM CARRIER ROTATOR. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 113. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 14 model references for this family. The first listed model is PMPS-50M. Compare the model rows and confirm the required configuration when quoting.
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
