| MODEL NUMBER | DESCRIPTION | FORK SIZE (W x L) | UNIFORM CAPACITY | SERVICE RANGE | WEIGHT (POUND) |
|---|---|---|---|---|---|
| TAL-220-HD | FOOT PUMP | 21" x 43½" | 2,200 lb. | 3½" to 33" | 356 |
| TAL-260-HD | FOOT PUMP | 27" x 43" | 2,200 lb. | 3½" to 33" | 385 |
| TAL-220-DC | 12V DC | 21" x 43" | 2,200 lb. | 3½" to 33" | 471 |
| TAL-260-DC | 12V DC | 27" x 43" | 2,200 lb. | 3½" to 33" | 474 |
| TOTE-A-LOAD OPTIONS MODEL NUMBER | DESCRIPTION | WEIGHT (POUND) |
|---|---|---|
| TAL-PLATE-21 | 21¼" WIDE SOLID PLATFORM TO FIT OVER FORKS | 36 |
| TAL-PLATE-27 | 27¾" WIDE SOLID PLATFORM TO FIT OVER FORKS | 38 |
| Fork Size (W X L) | 21" x 43½"; 27" x 43"; 21" x 43" |
|---|---|
| Uniform Capacity | 2,200 lb. |
| Service Range | 3½" to 33" |
Source: 2018 catalog, page 112. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The catalog lists TAL-220-HD through TAL-PLATE-27 within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Fork Size (W X L): 21" x 43½"; 27" x 43"; 21" x 43"; Uniform Capacity: 2,200 lb.. These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 12V. Confirm which apply to the selected model or optional power package.
The catalog entry describes foot-pump actuation, onboard charging. Check the configuration table and quote details to establish which features apply to your selection.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 112. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 6 model references for this family. The first listed model is TAL-220-HD. Compare the model rows and confirm the required configuration when quoting.
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
