| Model / reference | Wheels | Fork Size L x W (in) | Brake | Dimensions W x D x H (in) | Capacity (lb) | Weight (lb) |
|---|---|---|---|---|---|---|
| F89086 | (2) 121/2” Front Pneumatic & (2) 8” Rear Solid Rubber | 133/4 x 4 | Hand Brake | 27 x 33 x 57 | 800 | 190 |
| Wheels | (2) 121/2” Front Pneumatic & (2) 8” Rear Solid Rubber |
|---|---|
| Fork Size L x W (in) | 133/4 x 4 |
| Brake | Hand Brake |
| Dimensions W x D x H (in) | 27 x 33 x 57 |
| Capacity (lb) | 800 |
| Weight (lb) | 190 |
| Catalog feature / option | Stringer height of 1 ½” to meet your needs. |
| Catalog feature / option | Powered drive improves safety when moving heavy payloads. |
| Catalog feature / option | Foot operated trip spring allows forks to fold down or up. |
| Catalog feature / option | Fold forks up for compact storage or against the wall on a delivery truck. |
| Catalog feature / option | Fold forks down to easily push under your pallet or load. |
| Catalog feature / option | Once forks are under desired load, lift truck to lock forks in place and break-back load for transport. |
Source: 2025 storage and handling catalog, PDF page 44. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Powered Pallet Hand Truck is presented here with the configurations documented in the 2025 storage and handling catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.
Catalog features and options: Designed specifically for use with Pallet Trucks.; Stringer height of 1 ½” to meet your needs.; Keep inventory and valuables off the ground: clean and safe, simple to transport, assists in regulatory compliance. Foot Operated Trip Spring Foldable Forks; Powered drive improves safety when moving heavy payloads.; Efficiently transport product throughout facilities or on the go.; Foot operated trip spring allows forks to fold down or up.; Fold forks up for compact storage or against the wall on a delivery truck.; Fold forks down to easily push under your pallet or load.; Once forks are under desired load, lift truck to lock forks in place and break-back load for transport.; Designed to work with Plastic Mini-Pallets.; Full function forward and reverse with reverse audible warning.; Ergonomic design with rubber grip twin handles and full loop handle.; Hand brake gives operators added control and safety.; Built-in 18 AH rechargeable battery with monitor display.; Steel frame for heavy duty, rigorous applications.; Premium powder coat paint finish.; Ships fully assembled, ready to use..
Reference: 2025 storage and handling catalog, PDF page 44. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.
These specifications come from the 2025 storage and handling catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.
Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
