| Model / configuration | Load Capacity | Raised Height | Lowered Height | Dimensions H x W x L | Platform W x L | Lifting Speed — empty | Power Unit | On Board Charger | Shipping Weight |
|---|---|---|---|---|---|---|---|---|---|
| PLS52-185 | 185 lbs | 56" | 5" | 63 x 23-1/2 x 31" | 23-1/2 x 18-1/2" | 17 sec | 24VDC | 115 Volt | 105 lbs |
| PLS60-220 | 220 lbs | 65" | 5-1/8" | 76 x 23-1/2 x 33" | 23-1/2 x 18-1/2" | 20 sec | 24VDC | 115 Volt | 147 lbs |
| PLS48-450 | 445 lbs | 52" | 4-1/8" | 63 x 22 x 40" | 22 x 23-1/2" | 22 sec | 24VDC | 115 Volt | 190 lbs |
| Manufacturer | Presto |
|---|---|
| Catalog range | LiftStik Chain-Drive Lifter Transporters |
| Documented configurations | 3 |
| Power Unit | 24VDC |
| On Board Charger | 115 Volt |
Source: Presto General Catalog 2026, PDF page 7. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
This LiftStik range positions lighter loads using a continuous lifting chain with two speeds and a platform mounted on the forks.
Compare platform size and raised height across the three rows. PLS48-450 is rated at 445 lb despite its model suffix; use the documented rating. Published lift times are empty-unit times.
Reference: Presto General Catalog 2026, PDF page 7. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Compare platform size and raised height across the three rows. PLS48-450 is rated at 445 lb despite its model suffix; use the documented rating. Published lift times are empty-unit times.
For LiftStik Chain-Drive Lifter Transporters, include the selected model or configuration, quantity, load size and weight, operating requirements, delivery address and needed-by date. Request current drawings, freight and installation details for that selection.
Equipment details
Custom-series LiftStik lifters combine battery lifting with fixed or adjustable base legs and UHMW or stainless-steel work platforms.
Equipment details
PLS53 compact lifters provide a smaller mobile positioning format with a standard platform or V-cradle for different load shapes.
Equipment details
WP work positioners use a low mast and non-straddle forks to raise open-bottom pallets or skids within a work cell.
