| NO. OF STEPS | TOP STEP HEIGHT | OVERALL (W x D x H) | WEIGHT (POUND) | MODEL NUMBER GRIP STRUT STEPS | MODEL NUMBER PERFORATED STEPS |
|---|---|---|---|---|---|
| 4 | 40" | 28" x 41½" x 70" | 112 | LAD-RAF-4-G | LAD-RAF-4-P |
| 5 | 50" | 28" x 47 5/8" x 80" | 166 | LAD-RAF-5-G | LAD-RAF-5-P |
| 6 | 60" | 28" x 53¾" x 90" | 182 | LAD-RAF-6-G | LAD-RAF-6-P |
| 7 | 70" | 28" x 60 5/8" x 100" | 218 | LAD-RAF-7-G | LAD-RAF-7-P |
| 8 | 80" | 34¼" x 66 3/8" x 110" | 258 | LAD-RAF-8-24-G | LAD-RAF-8-24-P |
| 9 | 90" | 34¼" x 72 9/16" x 120" | 284 | LAD-RAF-9-24-G | LAD-RAF-9-24-P |
| 10 | 100" | 34¼" x 78 7/8" x 130" | 375 | LAD-RAF-10-24-G | LAD-RAF-10-24-P |
| 11 | 110" | 34¼" x 85 1/8" x 140" | 376 | LAD-RAF-11-24-G | LAD-RAF-11-24-P |
| 12 | 120" | 34¼" x 91" x 156" | 378 | LAD-RAF-12-24-G | LAD-RAF-12-24-P |
| 4 | 40" | 28" x 45 13/16" x 70" | 114 | LAD-RAF-4-G-EZ | LAD-RAF-4-P-EZ |
| 5 | 50" | 28" x 54 5/16" x 80" | 168 | LAD-RAF-5-G-EZ | LAD-RAF-5-P-EZ |
| 6 | 60" | 28" x 64 5/8" x 90" | 208 | LAD-RAF-6-G-EZ | LAD-RAF-6-P-EZ |
| 7 | 70" | 28" x 70 13/16" x 100" | 220 | LAD-RAF-7-G-EZ | LAD-RAF-7-P-EZ |
| 8 | 80" | 34¼" x 77" x 110" | 256 | LAD-RAF-8-24-G-EZ | LAD-RAF-8-24-P-EZ |
| 9 | 90" | 34¼" x 89 5/8" x 120" | 312 | LAD-RAF-9-24-G-EZ | LAD-RAF-9-24-P-EZ |
| 10 | 100" | 34¼" x 95 13/16" x 130" | 322 | LAD-RAF-10-24-G-EZ | LAD-RAF-10-24-P-EZ |
| 11 | 110" | 34¼" x 102¾" x 140" | 364 | LAD-RAF-11-24-G-EZ | LAD-RAF-11-24-P-EZ |
| 12 | 120" | 34¼" x 113 5/16" x 156" | 384 | LAD-RAF-12-24-G-EZ | LAD-RAF-12-24-P-EZ |
| NO. OF STEPS | TOP STEP HEIGHT | OVERALL (W x D x H) | WEIGHT (POUND) | MODEL NUMBER GRIP STRUT STEPS | MODEL NUMBER PERFORATED STEPS |
|---|---|---|---|---|---|
| 4 | 40" | 28" x 41½" x 70" | 112 | LAD-RAF-4-G | LAD-RAF-4-P |
| 5 | 50" | 28" x 47 5/8" x 80" | 166 | LAD-RAF-5-G | LAD-RAF-5-P |
| 6 | 60" | 28" x 53¾" x 90" | 182 | LAD-RAF-6-G | LAD-RAF-6-P |
| 7 | 70" | 28" x 60 5/8" x 100" | 218 | LAD-RAF-7-G | LAD-RAF-7-P |
| 8 | 80" | 34¼" x 66 3/8" x 110" | 258 | LAD-RAF-8-24-G | LAD-RAF-8-24-P |
| 9 | 90" | 34¼" x 72 9/16" x 120" | 284 | LAD-RAF-9-24-G | LAD-RAF-9-24-P |
| 10 | 100" | 34¼" x 78 7/8" x 130" | 375 | LAD-RAF-10-24-G | LAD-RAF-10-24-P |
| 11 | 110" | 34¼" x 85 1/8" x 140" | 376 | LAD-RAF-11-24-G | LAD-RAF-11-24-P |
| 12 | 120" | 34¼" x 91" x 156" | 378 | LAD-RAF-12-24-G | LAD-RAF-12-24-P |
| 4 | 40" | 28" x 45 13/16" x 70" | 114 | LAD-RAF-4-G-EZ | LAD-RAF-4-P-EZ |
| 5 | 50" | 28" x 54 5/16" x 80" | 168 | LAD-RAF-5-G-EZ | LAD-RAF-5-P-EZ |
| 6 | 60" | 28" x 64 5/8" x 90" | 208 | LAD-RAF-6-G-EZ | LAD-RAF-6-P-EZ |
| 7 | 70" | 28" x 70 13/16" x 100" | 220 | LAD-RAF-7-G-EZ | LAD-RAF-7-P-EZ |
| 8 | 80" | 34¼" x 77" x 110" | 256 | LAD-RAF-8-24-G-EZ | LAD-RAF-8-24-P-EZ |
| 9 | 90" | 34¼" x 89 5/8" x 120" | 312 | LAD-RAF-9-24-G-EZ | LAD-RAF-9-24-P-EZ |
| 10 | 100" | 34¼" x 95 13/16" x 130" | 322 | LAD-RAF-10-24-G-EZ | LAD-RAF-10-24-P-EZ |
| 11 | 110" | 34¼" x 102¾" x 140" | 364 | LAD-RAF-11-24-G-EZ | LAD-RAF-11-24-P-EZ |
| 12 | 120" | 34¼" x 113 5/16" x 156" | 384 | LAD-RAF-12-24-G-EZ | LAD-RAF-12-24-P-EZ |
Structured specifications are not listed in the source catalog. Refer to the product information above and ask our team to confirm the required configuration.
Source: 2018 catalog, page 234. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Compare the documented dimensions, capacities and model options with the intended application. Include installation, access and operating requirements when requesting a quote.
The catalog lists LAD-RAF-4-G through LAD-RAF-12-24-P-EZ within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 234. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 36 model references for this family. The first listed model is LAD-RAF-4-G. Compare the model rows and confirm the required configuration when quoting.
Choose an access configuration around the required standing height, approach and available floor space. Check the model’s dimensions against the work area before selecting it.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
