SKU RMH-C-5020-3
Reel Mover Handle
Reel Mover Handle: 1 catalog model references. Max Reel Height: 54"; Max Reel Length: 20 11/16".
- Max Reel Height
- 54"
- Max Reel Length
- 20 11/16"
Open an image to inspect its original detail.
Specifications & options
| TYPE | MODEL NUMBER | OVERALL SIZE (W x D x H) | INSIDE HOSE DIAMETER | LENGTH OF HOSE | WEIGHT (POUND) |
|---|---|---|---|---|---|
| A | VHR-20-44 | 6¼" x 15" x 15" | 1/4" | 20 FOOT | 19 |
| A | VHR-35-44 | 5½" x 12½" x 13" | 1/4" | 35 FOOT | 31 |
| A | VHR-17-46 | 6" x 15" x 15½" | 3/8" | 17 FOOT | 31 |
| A | VHR-25-46 | 6½" x 14¾" x 15½" | 3/8" | 25 FOOT | 26 |
| A | VHR-50-56 | 7½" x 19½" x 20" | 3/8" | 50 FOOT | 43 |
| B | VHR-35-58 | 8" x 9¼" x 18" | 1/2" | 35 FOOT | 43 |
| B | VHR-50-78 | 8¼" x 21" x 19¾" | 1/2" | 50 FOOT | 55 |
| Type | A; B |
|---|---|
| Overall Size (W X D X H) | 6¼" x 15" x 15"; 5½" x 12½" x 13"; 6" x 15" x 15½"; 6½" x 14¾" x 15½"; 7½" x 19½" x 20"; 8" x 9¼" x 18"; 8¼" x 21" x 19¾" |
| Inside Hose Diameter | 1/4"; 3/8"; 1/2" |
| Length Of Hose | 20 FOOT; 35 FOOT; 17 FOOT; 25 FOOT; 50 FOOT |
Source: 2018 catalog, page 72. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Equipment overview
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
The catalog lists VHR-20-44 through VHR-50-78 within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Type: A; B; Overall Size (W X D X H): 6¼" x 15" x 15"; 5½" x 12½" x 13"; 6" x 15" x 15½"; 6½" x 14¾" x 15½"; 7½" x 19½" x 20"; 8" x 9¼" x 18"; 8¼" x 21" x 19¾". These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Documentation & drawings
Reference: 2018 product catalog, page 72. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
Which models are listed for spring driven low pressure hose reels?
The catalog records 7 model references for this family. The first listed model is VHR-20-44. Compare the model rows and confirm the required configuration when quoting.
How do I choose the right spring driven low pressure hose reels configuration?
Compare the documented model configurations with the task, available space and installation conditions. Include the relevant dimensions and operating requirements in your quote request.
Are these current product specifications?
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
