| MODEL NUMBER | LOWERED HEIGHT | RAISED HEIGHT | *CAPACITY 0"-63" RH | *CAPACITY 63"-118" RH | *CAPACITY 118"-137" RH | *CAPACITY 137"-150" RH | WEIGHT (POUND) |
|---|---|---|---|---|---|---|---|
| SL-63-AA | 2 1/8" | 63" | 2,000 lb. | --- | --- | --- | 1132 |
| SL-118-AA | 2 1/8" | 118" | 2,000 lb. | 1,500 lb. | --- | --- | 1294 |
| SL-137-AA | 2 1/8" | 137" | 2,000 lb. | 1,500 lb. | 1,000 lb. | --- | 1289 |
| SL-150-AA | 2 1/8" | 150" | 2,000 lb. | 1,500 lb. | 1,000 lb. | 750 lb. | 1359 |
| SL-63-FF | 3 3/8" | 63" | 2,000 lb. | --- | --- | --- | 1010 |
| SL-118-FF | 3 3/8" | 118" | 2,000 lb. | 1,500 lb. | --- | --- | 1349 |
| SL-HC | HAND CONTROL | 3 | |||||
| SL-DK | SOLID PLATFORM | 46 | |||||
| SL-PTDS | POWER TRACTION DRIVE SYSTEM | --- | |||||
| AGM-UPG-SL | Must purchase with new unit | AGM BATTERY UPGRADE (1) 12V | 68 |
| Lowered Height | 2 1/8"; 3 3/8" |
|---|---|
| Raised Height | 63"; 118"; 137"; 150"; HAND CONTROL; SOLID PLATFORM; Must purchase with new unit |
| *Capacity 0"-63" Rh | 2,000 lb.; POWER TRACTION DRIVE SYSTEM; AGM BATTERY UPGRADE (1) 12V |
| *Capacity 63"-118" Rh | ---; 1,500 lb. |
| *Capacity 118"-137" Rh | ---; 1,000 lb. |
| *Capacity 137"-150" Rh | ---; 750 lb. |
Source: 2018 catalog, page 115. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The catalog lists SL-63-AA through AGM-UPG-SL within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Lowered Height: 2 1/8"; 3 3/8"; Raised Height: 63"; 118"; 137"; 150"; HAND CONTROL; SOLID PLATFORM; Must purchase with new unit. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 115. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 10 model references for this family. The first listed model is SL-63-AA. Compare the model rows and confirm the required configuration when quoting.
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
