| Model / reference | Capacity | Voltage | Height | Fork |
|---|---|---|---|---|
| SL SS WCB 10 — Capacity: 1,000 lbs; Voltage: 24 V; Height: 36” x 154” | 1,000 lbs | 24 V | 36” x 154” | — |
| SL SS WCB 10 — Capacity: 2,000 lbs; Voltage: 24 V; Height: 36” x 154” | 2,000 lbs | 24 V | 36” x 154” | 36”-72” long |
| SL SS WCB 10 — Capacity: 2,500 lbs; Voltage: 24 V; Height: 36” x 154” | 2,500 lbs | 24 V | 36” x 154” | 12”-48” wide |
| SL SS WCB 10 — Capacity: 3,000 lbs; Voltage: 24 V; Height: 36” x 154” | 3,000 lbs | 24 V | 36” x 154” | — |
| Documented model configurations | 4 |
|---|---|
| Voltage | 24 V |
| Height | 36” x 154” |
| Catalog feature / option | 100% Stainless steel frame carriage, forks and undercarriage |
| Catalog feature / option | Available in 304L and 316L stainless steel |
| Catalog feature / option | Capacities 500 to 5,000 lbs |
| Catalog feature / option | Custom fork sizes |
| Catalog feature / option | Lift heights to 189 inches |
| Catalog feature / option | Rider platforms |
| Catalog feature / option | Straddle trucks, counterbalance fork over and walkie reach trucks are all available Stainless Steel Counterbalance Stacker |
Source: 2019 sanitary equipment catalog, PDF page 14. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Stainless Steel Counterbalance Stackers is presented here with the configurations documented in the 2019 sanitary equipment catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.
Catalog features and options: 100% Stainless steel frame carriage, forks and undercarriage; Available in 304L and 316L stainless steel; Capacities 500 to 5,000 lbs; Finishes 2B, electro polished and 35 RA; For Food, pharmaceutical, chemical and other washdown applications; Custom fork sizes; Lift heights to 189 inches; Custom designs; Epoxy coatings, galvanized, nickel plated and linex coatings available; Rider platforms; Horizontal travel models; Straddle trucks, counterbalance fork over and walkie reach trucks are all available Stainless Steel Counterbalance Stacker.
The source describes standard and custom equipment. Confirm the current construction, control system, finish, installation details and selected operating limits with your quote.
Reference: 2019 sanitary equipment catalog, PDF page 14. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.
These specifications come from the 2019 sanitary equipment catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.
Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
