Stainless Steel Economy Hydraulic Lift Tables — catalog equipment photograph

Open an image to inspect its original detail.

Stainless Steel Economy Hydraulic Lift Tables — catalog equipment photographStainless Steel Economy Hydraulic Lift Tables — catalog equipment photographStainless Steel Economy Hydraulic Lift Tables — catalog equipment photograph

Specifications & options

Model / referenceCapacityMaterialPlatformLowered heightRaised height
SL B SS50500 kg / 1,102 lb304 Stainless steel828 x 498 mm / 32.6 x 19.7 in330 mm / 13 in950 mm / 37.4 in
SL B SS1001,000 kg / 2,204 lb304 Stainless steel1,010 x 520 mm / 39.75 x 20.5 in444 mm / 17.5 in950 mm / 37.4 in
Documented model configurations2
Material304 Stainless steel
Raised height950 mm / 37.4 in
Catalog feature / optionHigh quality 304L and 316L stainless steel
Catalog feature / optionCapacities 150 kg to 1,000 kg
Catalog feature / optionBuilt-in relief valve to fulfil overload protection.

Source: 2019 sanitary equipment catalog, PDF page 2. Confirm the current selected configuration with your quote.

PRODUCT INFORMATION

Equipment overview

Stainless Steel Economy Hydraulic Lift Tables is presented here with the configurations documented in the 2019 sanitary equipment catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.

Catalog features and options: High quality 304L and 316L stainless steel; Capacities 150 kg to 1,000 kg; Safety clearance between scissors to prevent from trapping; Swivel wheel with protection frame and brake to prevent foot from injury; Built-in relief valve to fulfil overload protection.; For use in food and medicine industry.

The source describes standard and custom equipment. Confirm the current construction, control system, finish, installation details and selected operating limits with your quote.

Documentation & drawings

Reference: 2019 sanitary equipment catalog, PDF page 2. The tables reproduce the documented configurations.

Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.

Request model documentation ↗

Questions about this equipment

How do I choose a model or configuration?

Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.

Are the catalog specifications current?

These specifications come from the 2019 sanitary equipment catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.

How do I request a quote?

Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
