Stainless Steel Portable Single and Double Lift Tables — catalog equipment photograph

Open an image to inspect its original detail.

Stainless Steel Portable Single and Double Lift Tables — catalog equipment photographStainless Steel Portable Single and Double Lift Tables — catalog equipment photograph

Specifications & options

Model / referenceCapacityLowered liftRaised heightPlatform sizeLower Height
SL SS34-05500 lbs16”34”24” x 36”36” x 48”
SL SS34-101,000 lbs16”34”24” x 36”36” x 48”
SL SSD54-05500 lbs18”72”24” x 36”36” x 48”
SL SSD54-101,000 lbs18”72”24” x 36”36” x 48”
SL SSP34-05500 lbs16”34”24” x 36”48” x 60”
SL SSP34-101,000 lbs16”34”24” x 36”48” x 60”
SL SSP34-151,500 lbs16”34”24” x 36”48” x 60”
SL SSP34-202,000 lbs16”34”24” x 36”48” x 60”
SL SSP60-05500 lbs18”78”36” x 48”60” x 72”
SL SSP60-101,000 lbs18”78”36” x 48”60” x 72”
SL SSP60-151,500 lbs18”78”36” x 48”60” x 72”
Documented model configurations11
Catalog feature / optionHigh quality 304L and 316L stainless steel
Catalog feature / optionPlatform sizes to 48” x 72” (1,200mm x 1,600 mm)
Catalog feature / optionLift heights to 78” high

Source: 2019 sanitary equipment catalog, PDF page 9. Confirm the current selected configuration with your quote.

PRODUCT INFORMATION

Equipment overview

Stainless Steel Portable Single and Double Lift Tables is presented here with the configurations documented in the 2019 sanitary equipment catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.

Catalog features and options: High quality 304L and 316L stainless steel; Foot pump and powered lift available; Delrin rollers and bushings; Battery powered, air powered and A/C powered; Platform sizes to 48” x 72” (1,200mm x 1,600 mm); Lift heights to 78” high; Nickel plated and stainless and washdown pumps.

Model and option notes: SL SSP60-20 SL SSP60-30 SL SSP60-40; 2,000 lbs 3,000 lbs 4,000 lbs; 18” 18” 18”; 78” 78” 78”; 36” x 48” 36” x 48” 36” x 48”; 60” x 72” 60” x 72” 60” x 72”.

The source describes standard and custom equipment. Confirm the current construction, control system, finish, installation details and selected operating limits with your quote.

Documentation & drawings

Reference: 2019 sanitary equipment catalog, PDF page 9. The tables reproduce the documented configurations.

Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.

Request model documentation ↗

Questions about this equipment

How do I choose a model or configuration?

Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.

Are the catalog specifications current?

These specifications come from the 2019 sanitary equipment catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.

How do I request a quote?

Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
