| MODEL NUMBER | VOLUME CUBIC YARDS | UNIFORM CAPACITY | OVERALL SIZE (W x L x H) | WEIGHT (POUND) |
|---|---|---|---|---|
| TDT-50-LD-BLACK | 1/2 | 450 lb. | 28" x 62" x 35" | 91 |
| TDT-50-LD-BLUE | 1/2 | 450 lb. | 28" x 62" x 35" | 91 |
| TDT-50-LD-RED | 1/2 | 450 lb. | 28" x 62" x 35" | 91 |
| TDT-50-LD-YELLOW | 1/2 | 450 lb. | 28" x 62" x 35" | 91 |
| TDT-50-MD-BLACK | 1/2 | 850 lb. | 28" x 62" x 35" | 108 |
| TDT-50-MD-BLUE | 1/2 | 850 lb. | 28" x 62" x 35" | 108 |
| TDT-50-MD-RED | 1/2 | 850 lb. | 28" x 62" x 35" | 108 |
| TDT-50-MD-YELLOW | 1/2 | 850 lb. | 28" x 62" x 35" | 108 |
| TDT-50-HD-BLACK | 1/2 | 1,400 lb. | 28" x 62" x 35" | 113 |
| TDT-50-HD-BLUE | 1/2 | 1,400 lb. | 28" x 62" x 35" | 113 |
| TDT-50-HD-RED | 1/2 | 1,400 lb. | 28" x 62" x 35" | 113 |
| TDT-50-HD-YELLOW | 1/2 | 1,400 lb. | 28" x 62" x 35" | 113 |
| TDT-100-LD-BLACK | 1 | 850 lb. | 32" x 73" x 42" | 113 |
| TDT-100-LD-BLUE | 1 | 850 lb. | 32" x 73" x 42" | 113 |
| TDT-100-LD-RED | 1 | 850 lb. | 32" x 73" x 42" | 113 |
| TDT-100-LD-YELLOW | 1 | 850 lb. | 32" x 73" x 42" | 113 |
| TDT-100-MD-BLACK | 1 | 1,250 lb. | 32" x 73" x 43" | 135 |
| TDT-100-MD-BLUE | 1 | 1,250 lb. | 32" x 73" x 43" | 135 |
| TDT-100-MD-RED | 1 | 1,250 lb. | 32" x 73" x 43" | 135 |
| TDT-100-MD-YELLOW | 1 | 1,250 lb. | 32" x 73" x 43" | 135 |
| TDT-100-HD-BLACK | 1 | 2,100 lb. | 32" x 73" x 43" | 140 |
| TDT-100-HD-BLUE | 1 | 2,100 lb. | 32" x 73" x 43" | 140 |
| TDT-100-HD-RED | 1 | 2,100 lb. | 32" x 73" x 43" | 140 |
| TDT-100-HD-YELLOW | 1 | 2,100 lb. | 32" x 73" x 43" | 140 |
| Volume Cubic Yards | 1/2; 1 |
|---|---|
| Uniform Capacity | 450 lb.; 850 lb.; 1,400 lb.; 1,250 lb.; 2,100 lb. |
| Overall Size (W X L X H) | 28" x 62" x 35"; 32" x 73" x 42"; 32" x 73" x 43" |
Source: 2018 catalog, page 70. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The catalog lists TDT-50-LD-BLACK through TDT-100-HD-YELLOW within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Volume Cubic Yards: 1/2; 1; Uniform Capacity: 450 lb.; 850 lb.; 1,400 lb.; 1,250 lb.; 2,100 lb.. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 70. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 24 model references for this family. The first listed model is TDT-50-LD-BLACK. Compare the model rows and confirm the required configuration when quoting.
Consider the load dimensions, route width and loading or unloading method together. Check the selected configuration’s listed capacity and dimensions against the job.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
