SKU 7-13764
GKS Robot 40 Lift Battery powered remote controlled transport system with integrated lift table
Battery powered remote controlled transport system with integrated lift table
- Power source
- Battery powered
- Loading height
- 9.8 inch
Open an image to inspect its original detail.
Specifications & options
| MODEL NUMBER | PLATFORM (W x L) | LOWERED HEIGHT | RAISED HEIGHT | UNIFORM CAPACITY | OVERALL FRAME SIZE (W x L) | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| WL-100-5-48 | 48" x 96" | 8" | 68" | 5,000 lb. | 41" x 93" | 2856 |
| WL-100-5-68 | 72" x 96" | 8" | 68" | 5,000 lb. | 62" x 93" | 3501 |
| WL-100-5-78 | 84" x 96" | 8" | 68" | 5,000 lb. | 62" x 93" | 3750 |
| WL-100-5-88* | 96" x 96" | 8" | 68" | 5,000 lb. | 86" x 93" | 3996 |
| WL-100-5-610 | 72" x 120" | 8" | 68" | 5,000 lb. | 62" x 118" | 3867 |
| WL-100-5-710 | 84" x 120" | 8" | 68" | 5,000 lb. | 62" x 118" | 4071 |
| WL-100-5-810* | 96" x 120" | 8" | 68" | 5,000 lb. | 86" x 118" | 4151 |
| WL-100-6-68 | 72" x 96" | 10" | 70" | 6,000 lb. | 62" x 93" | 3415 |
| WL-100-6-78 | 84" x 96" | 10" | 70" | 6,000 lb. | 62" x 93" | 3616 |
| WL-100-6-88* | 96" x 96" | 10" | 70" | 6,000 lb. | 86" x 93" | 4211 |
| WL-100-6-610 | 72" x 120" | 10" | 70" | 6,000 lb. | 62" x 118" | 3983 |
| WL-100-6-710 | 84" x 120" | 10" | 70" | 6,000 lb. | 62" x 118" | 4082 |
| WL-100-6-810* | 96" x 120" | 10" | 70" | 6,000 lb. | 86" x 118" | 4345 |
| WL-100-8-68 | 72" x 96" | 10" | 70" | 8,000 lb. | 62" x 93" | 4440 |
| WL-100-8-78 | 84" x 96" | 10" | 70" | 8,000 lb. | 62" x 93" | 4636 |
| WL-100-8-88* | 96" x 96" | 10" | 70" | 8,000 lb. | 86" x 93" | 4742 |
| WL-100-8-610 | 72" x 120" | 10" | 70" | 8,000 lb. | 62" x 118" | 4851 |
| WL-100-8-710 | 84" x 120" | 10" | 70" | 8,000 lb. | 62" x 118" | 4957 |
| WL-100-8-810* | 96" x 120" | 10" | 70" | 8,000 lb. | 86" x 118" | 5201 |
| WL-100-10-68 | 72" x 96" | 14" | 72" | 10,000 lb. | 62" x 93" | 5848 |
| WL-100-10-78 | 84" x 96" | 14" | 72" | 10,000 lb. | 62" x 93" | 6035 |
| WL-100-10-88* | 96" x 96" | 14" | 72" | 10,000 lb. | 86" x 93" | 6221 |
| WL-100-10-610 | 72" x 120" | 14" | 72" | 10,000 lb. | 62" x 118" | 6081 |
| WL-100-10-710 | 84" x 120" | 14" | 72" | 10,000 lb. | 62" x 118" | 6268 |
| WL-100-10-810* | 96" x 120" | 14" | 72" | 10,000 lb. | 86" x 118" | 6454 |
| WL-100-10-612 | 72" x 144" | 14" | 72" | 10,000 lb. | 62" x 118" | 6548 |
| WL-100-10-712 | 84" x 144" | 14" | 72" | 10,000 lb. | 62" x 118" | 6734 |
| WL-100-10-812* | 96" x 144" | 14" | 72" | 10,000 lb. | 86" x 118" | 6920 |
| WL-100-12-68 | 72" x 96" | 14" | 72" | 12,000 lb. | 62" x 93" | 6431 |
| WL-100-12-78 | 84" x 96" | 14" | 72" | 12,000 lb. | 62" x 93" | 6617 |
| WL-100-12-88* | 96" x 96" | 14" | 72" | 12,000 lb. | 86" x 93" | 6775 |
| WL-100-12-610 | 72" x 120" | 14" | 72" | 12,000 lb. | 62" x 118" | 6664 |
| WL-100-12-710 | 84" x 120" | 14" | 72" | 12,000 lb. | 62" x 118" | 6851 |
| WL-100-12-810* | 96" x 120" | 14" | 72" | 12,000 lb. | 86" x 118" | 7037 |
| WL-100-12-612 | 72" x 144" | 14" | 72" | 12,000 lb. | 62" x 118" | 7142 |
| WL-100-12-712 | 84" x 144" | 14" | 72" | 12,000 lb. | 62" x 118" | 7269 |
| WL-100-12-812* | 96" x 144" | 14" | 72" | 12,000 lb. | 86" x 118" | 7480 |
| Lowered Height | 8"; 10"; 14" |
|---|---|
| Raised Height | 68"; 70"; 72" |
| Uniform Capacity | 5,000 lb.; 6,000 lb.; 8,000 lb.; 10,000 lb.; 12,000 lb. |
| Overall Frame Size (W X L) | 41" x 93"; 62" x 93"; 86" x 93"; 62" x 118"; 86" x 118" |
Source: 2018 catalog, page 8. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Equipment overview
Compare the documented dimensions, capacities and model options with the intended application. Include installation, access and operating requirements when requesting a quote.
The catalog lists WL-100-5-48 through WL-100-12-812 within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Lowered Height: 8"; 10"; 14"; Raised Height: 68"; 70"; 72". These values cover multiple models; consult the individual row for the model being quoted.
Power details mentioned in the catalog entry include 6.5 HP, 460V, 60 Hz. Confirm which apply to the selected model or optional power package.
The catalog entry describes push-button controls. Check the configuration table and quote details to establish which features apply to your selection.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Documentation & drawings
Reference: 2018 product catalog, page 8. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
Which models are listed for truck dock scissor lift platforms?
The catalog records 37 model references for this family. The first listed model is WL-100-5-48. Compare the model rows and confirm the required configuration when quoting.
How do I choose the right truck dock scissor lift platforms configuration?
Start with the load, lifting arrangement and clearance available for the task. Compare each model’s listed operating dimensions and capacity rather than treating the family as one interchangeable configuration.
Are these current product specifications?
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
