Equipment details
WP-400-AC electric work platform
Achieve Optimal Efficiency: The Linearize Electric Worker Platform
- Platform dimensions
- 36” x 24”
- Capacity
- 400 pounds
Open an image to inspect its original detail.
Specifications & options
| MODEL NUMBER | PLATFORM SIZE (W x L) | FORK POCKET CENTERS | EXPANDED METAL BACK HEIGHT | WEIGHT (POUND) |
|---|---|---|---|---|
| WP-3636 | 36" x 36" | 16" | 60" | 146 |
| WP-3648 | 36" x 48" | 16" | 60" | 165 |
| WP-4848 | 48" x 48" | 24" | 60" | 195 |
| WP-4848-FF | 48" x 48" | 24" | 60" | 208 |
| WP-3636-84B | 36" x 36" | 16" | 84" | 151 |
| WP-3648-84B | 36" x 48" | 16" | 84" | 175 |
| WP-4848-84B | 48" x 48" | 24" | 84" | 205 |
| WP-4848-84B-FF | 48" x 48" | 24" | 84" | 218 |
| WP-3636-DD | 36" x 36" | 16" | 60" | 143 |
| WP-3648-DD | 36" x 48" | 16" | 60" | 175 |
| WP-4848-DD | 48" x 48" | 24" | 60" | 207 |
| WP-4848-DD-FF | 48" x 48" | 24" | 60" | 220 |
| WP-3636-84B-DD | 36" x 36" | 16" | 84" | 215 |
| WP-3648-84B-DD | 36" x 48" | 16" | 84" | 183 |
| WP-4848-84B-DD | 48" x 48" | 24" | 84" | 213 |
| WP-4848-84B-DD-FF | 48" X 48" | 24" | 84" | 226 |
| Platform Size (W X L) | 36" x 36"; 36" x 48"; 48" x 48"; 48" X 48" |
|---|---|
| Fork Pocket Centers | 16"; 24" |
| Expanded Metal Back Height | 60"; 84" |
Source: 2018 catalog, page 187. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Equipment overview
Choose an access configuration around the required standing height, approach and available floor space. Check the model’s dimensions against the work area before selecting it.
The catalog lists WP-3636 through WP-4848-84B-DD-FF within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Platform Size (W X L): 36" x 36"; 36" x 48"; 48" x 48"; 48" X 48"; Fork Pocket Centers: 16"; 24". These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Documentation & drawings
Reference: 2018 product catalog, page 187. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Questions about this equipment
Which models are listed for work platforms?
The catalog records 16 model references for this family. The first listed model is WP-3636. Compare the model rows and confirm the required configuration when quoting.
How do I choose the right work platforms configuration?
Choose an access configuration around the required standing height, approach and available floor space. Check the model’s dimensions against the work area before selecting it.
Are these current product specifications?
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
