Open an image to inspect its original detail.
| MODEL NUMBER | UNIFORM CAPACITY | OVERALL I-BEAM LENGTH & HEIGHT | I-BEAM FLANGE WIDTH | UNDER I-BEAM USABLE HEIGHT | BASE WIDTH | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| AHSN-2-10-12 | 2,000 lb. | 10' / 6" | 4" | 7'6" to 12' | 79 3/4" | 876 |
| AHSN-2-10-14 | 2,000 lb. | 10' / 6" | 4" | 8'6" to 14' | 91 1/2" | 952 |
| AHSN-2-10-16 | 2,000 lb. | 10' / 6" | 4" | 10'6" to 16' | 91 1/2" | 999 |
| AHSN-2-15-7 | 2,000 lb. | 15' / 6" | 4" | 5' to 7' | 50" | 740 |
| AHSN-2-15-9 | 2,000 lb. | 15' / 6" | 4" | 6' to 9' | 61 7/8" | 818 |
| AHSN-2-15-10 | 2,000 lb. | 15' / 6" | 4" | 6'6" to 10' | 67 13/16" | 855 |
| AHSN-2-15-12 | 2,000 lb. | 15' / 6" | 4" | 7'6" to 12' | 79 3/4" | 933 |
| AHSN-2-15-14 | 2,000 lb. | 15' / 6" | 4" | 8'6" to 14' | 91 1/2" | 1006 |
| AHSN-2-15-16 | 2,000 lb. | 15' / 6" | 4" | 10'6" to 16' | 91 1/2" | 1056 |
| AHSN-2-20-12 | 2,000 lb. | 20' / 10 1/8" | 4" | 7'6" to 12' | 79 3/4" | 1120 |
| AHSN-2-20-14 | 2,000 lb. | 20' / 10 1/8" | 4" | 8'6" to 14' | 91 1/2" | 1206 |
| AHSN-2-20-16 | 2,000 lb. | 20' / 10 1/8" | 4" | 10'6" to 16' | 91 1/2" | 1242 |
| AHSN-4-10-12 | 4,000 lb. | 10' / 8 1/8" | 4" | 7'6" to 12' | 79 3/4" | 909 |
| AHSN-4-10-14 | 4,000 lb. | 10' / 8 1/8" | 4" | 8'6" to 14' | 91 1/2" | 984 |
| AHSN-4-10-16 | 4,000 lb. | 10' / 8 1/8" | 4" | 10'6" to 16' | 91 1/2" | 1039 |
| AHSN-4-15-7 | 4,000 lb. | 15' / 8 1/8" | 4" | 5' to 7' | 50" | 786 |
| AHSN-4-15-9 | 4,000 lb. | 15' / 8 1/8" | 4" | 6' to 9' | 61 7/8" | 857 |
| AHSN-4-15-10 | 4,000 lb. | 15' / 8 1/8" | 4" | 6'6" to 10' | 67 13/16" | 908 |
| AHSN-4-15-12 | 4,000 lb. | 15' / 8 1/8" | 4" | 7'6" to 12' | 79 3/4" | 976 |
| AHSN-4-15-14 | 4,000 lb. | 15' / 8 1/8" | 4" | 8'6" to 14' | 91 1/2" | 1052 |
| AHSN-4-15-16 | 4,000 lb. | 15' / 8 1/8" | 4" | 10'6" to 16' | 91 1/2" | 1101 |
| AHSN-4-20-12 | 4,000 lb. | 20' / 12 3/16" | 4" | 7'6" to 12' | 79 3/4" | 1132 |
| AHSN-4-20-14 | 4,000 lb. | 20' / 12 3/16" | 4" | 8'6" to 14' | 91 1/2" | 1212 |
| AHSN-4-20-16 | 4,000 lb. | 20' / 12 3/16" | 4" | 10'6" to 16' | 91 1/2" | 1260 |
| AHSN-6-10-12 | 6,000 lb. | 10' / 8 1/8" | 4" | 7'7" to 12'1" | 76 1/4" | 991 |
| AHSN-6-10-14 | 6,000 lb. | 10' / 8 1/8" | 4" | 8'7" to 14'1" | 88" | 1051 |
| AHSN-6-10-16 | 6,000 lb. | 10' / 8 1/8" | 4" | 10'7" to 16'1" | 88" | 1109 |
| AHSN-6-15-7 | 6,000 lb. | 15' / 10 1/8" | 4" | 5'1" to 7'1" | 46 1/2" | 864 |
| AHSN-6-15-9 | 6,000 lb. | 15' / 10 1/8" | 4" | 6'1" to 9'1" | 58 3/8" | 934 |
| AHSN-6-15-10 | 6,000 lb. | 15' / 10 1/8" | 4" | 6'7" to 10'1" | 64 5/16" | 980 |
| AHSN-6-15-12 | 6,000 lb. | 15' / 10 1/8" | 4" | 7'7" to 12'1" | 76 1/4" | 1054 |
| AHSN-6-15-14 | 6,000 lb. | 15' / 10 1/8" | 4" | 8'7" to 14'1" | 88" | 1132 |
| AHSN-6-15-16 | 6,000 lb. | 15' / 10 1/8" | 4" | 10'7" to 16'1" | 88" | 1182 |
| AHSN-6-20-12 | 6,000 lb. | 20' / 12 5/16" | 6½" | 7'7" to 12'1" | 76 1/4" | 1449 |
| AHSN-6-20-14 | 6,000 lb. | 20' / 12 5/16" | 6½" | 8'7" to 14'1" | 88" | 1521 |
| AHSN-6-20-16 | 6,000 lb. | 20' / 12 5/16" | 6½" | 10'7" to 16'1" | 88" | 1569 |
| AHSN-8-10-12 | 8,000 lb. | 10' / 8 1/8" | 4" | 7'7" to 12'1" | 76 1/4" | 979 |
| AHSN-8-10-14 | 8,000 lb. | 10' / 8 1/8" | 4" | 8'7" to 14'1" | 88" | 1051 |
| AHSN-8-10-16 | 8,000 lb. | 10' / 8 1/8" | 4" | 10'7" to 16'1" | 88" | 1107 |
| AHSN-8-15-7 | 8,000 lb. | 15' / 10 1/8" | 4" | 5'1" to 7'1" | 46 1/2" | 862 |
| AHSN-8-15-9 | 8,000 lb. | 15' / 10 1/8" | 4" | 6'1" to 9'1" | 58 3/8" | 940 |
| AHSN-8-15-10 | 8,000 lb. | 15' / 10 1/8" | 4" | 6'7" to 10'1" | 64 5/16" | 974 |
| AHSN-8-15-12 | 8,000 lb. | 15' / 10 1/8" | 4" | 7'7" to 12'1" | 76 1/4" | 1050 |
| AHSN-8-15-14 | 8,000 lb. | 15' / 10 1/8" | 4" | 8'7" to 14'1" | 88" | 1142 |
| AHSN-8-15-16 | 8,000 lb. | 15' / 10 1/8" | 4" | 10'7" to 16'1" | 88" | 1182 |
| AHSN-8-20-12 | 8,000 lb. | 20' / 12 5/16" | 6½" | 7'7" to 12'1" | 76 1/4" | 1445 |
| AHSN-8-20-14 | 8,000 lb. | 20' / 12 5/16" | 6½" | 8'7" to 14'1" | 88" | 1523 |
| AHSN-8-20-16 | 8,000 lb. | 20' / 12 5/16" | 6½" | 10'7" to 16'1" | 88" | 1577 |
| AHSN-10-15-10 | 10,000 lb. | 15' / 12 3/16" | 4" | 6'7" to 10'1" | 64 5/16" | 1355 |
| AHSN-KIT | BEAM HEIGHT ADJUSTMENT KIT (2) weldment assembles, (2) slings | |||||
| AHS-STLO | STATIONARY LEG OPTION, set of (4) four | (factory installed) | ||||
| AHS-STLO-RF | STATIONARY LEG OPTION, set of (4) four | (field installed) |
| Uniform Capacity | 2,000 lb.; 4,000 lb.; 6,000 lb.; 8,000 lb.; 10,000 lb. |
|---|---|
| I-Beam Flange Width | 4"; 6½"; BEAM HEIGHT ADJUSTMENT KIT (2) weldment assembles, (2) slings |
Source: 2018 catalog, page 203. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Start with the load, lifting arrangement and clearance available for the task. Compare each model’s listed operating dimensions and capacity rather than treating the family as one interchangeable configuration.
The catalog lists AHSN-2-10-12 through AHS-STLO-RF within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Uniform Capacity: 2,000 lb.; 4,000 lb.; 6,000 lb.; 8,000 lb.; 10,000 lb.; I-Beam Flange Width: 4"; 6½"; BEAM HEIGHT ADJUSTMENT KIT (2) weldment assembles, (2) slings. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 203. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 52 model references for this family. The first listed model is AHSN-2-10-12. Compare the model rows and confirm the required configuration when quoting.
Start with the load, lifting arrangement and clearance available for the task. Compare each model’s listed operating dimensions and capacity rather than treating the family as one interchangeable configuration.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
