Open an image to inspect its original detail.
| MODEL NUMBER | NO. OF STEPS | TOP STEP HEIGHT | OVERALL HEIGHT | BASE SIZE (W x D) | TOP STEP DEPTH | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| LAD-6-14-G | 6 | 60" | 90" | 34¼" x 53 15/16" | 14" | 249 |
| LAD-7-14-G | 7 | 70" | 100" | 34¼" x 60 1/16" | 14" | 286 |
| LAD-8-14-G | 8 | 80" | 110" | 34¼" x 66 15/16" | 14" | 288 |
| LAD-9-14-G | 9 | 90" | 120" | 34¼" x 72 11/16" | 14" | 322 |
| LAD-10-14-G | 10 | 100" | 130" | 34¼" x 78 15/16" | 14" | 336 |
| LAD-11-14-G | 11 | 110" | 140" | 34¼" x 85 1/16" | 14" | 367 |
| LAD-6-21-G | 6 | 60" | 90" | 34¼" x 60" | 21" | 252 |
| LAD-7-21-G | 7 | 70" | 100" | 34¼" x 66 15/16" | 21" | 302 |
| LAD-8-21-G | 8 | 80" | 110" | 34¼" x 72 5/8" | 21" | 312 |
| LAD-9-21-G | 9 | 90" | 120" | 34¼" x 78 15/16" | 21" | 342 |
| LAD-10-21-G | 10 | 100" | 130" | 34¼" x 85 3/16" | 21" | 354 |
| LAD-11-21-G | 11 | 110" | 140" | 34¼" x 91¼" | 21" | 396 |
| LAD-6-14-P | 6 | 60" | 90" | 34¼" x 53 15/16" | 14" | 252 |
| LAD-7-14-P | 7 | 70" | 100" | 34¼" x 60 1/16" | 14" | 266 |
| LAD-8-14-P | 8 | 80" | 110" | 34¼" x 66 15/16" | 14" | 292 |
| LAD-9-14-P | 9 | 90" | 120" | 34¼" x 72 11/16" | 14" | 318 |
| LAD-10-14-P | 10 | 100" | 130" | 34¼" x 78 15/16" | 14" | 341 |
| LAD-11-14-P | 11 | 110" | 140" | 34¼" x 85 1/16" | 14" | 371 |
| LAD-6-21-P | 6 | 60" | 90" | 34¼" x 60" | 21" | 276 |
| LAD-7-21-P | 7 | 70" | 100" | 34¼" x 66 15/16" | 21" | 293 |
| LAD-8-21-P | 8 | 80" | 110" | 34¼" x 72 5/8" | 21" | 296 |
| LAD-9-21-P | 9 | 90" | 120" | 34¼" x 78 15/16" | 21" | 322 |
| LAD-10-21-P | 10 | 100" | 130" | 34¼" x 85 3/16" | 21" | 360 |
| LAD-11-21-P | 11 | 110" | 140" | 34¼" x 91¼" | 21" | 392 |
| LAD-6-14-G-EZ | 6 | 60" | 90" | 34¼" x 62 3/8" | 14" | 212 |
| LAD-7-14-G-EZ | 7 | 70" | 100" | 34¼" x 70 7/8" | 14" | 237 |
| LAD-8-14-G-EZ | 8 | 80" | 110" | 34¼" x 85 5/16" | 14" | 260 |
| LAD-9-14-G-EZ | 9 | 90" | 120" | 34¼" x 91½" | 14" | 281 |
| LAD-10-14-G-EZ | 10 | 100" | 130" | 34¼" x 97 11/16" | 14" | 344 |
| LAD-11-14-G-EZ | 11 | 110" | 140" | 34¼" x 103 7/8" | 14" | 376 |
| LAD-6-21-G-EZ | 6 | 60" | 90" | 34¼" x 70 15/16" | 21" | 223 |
| LAD-7-21-G-EZ | 7 | 70" | 100" | 34¼" x 78 15/16" | 21" | 248 |
| LAD-8-21-G-EZ | 8 | 80" | 110" | 34¼" x 91 9/16" | 21" | 271 |
| LAD-9-21-G-EZ | 9 | 90" | 120" | 34¼" x 97¾" | 21" | 292 |
| LAD-10-21-G-EZ | 10 | 100" | 130" | 34¼" x 103 15/16" | 21" | 348 |
| LAD-11-21-G-EZ | 11 | 110" | 140" | 34¼" x 110 7/8" | 21" | 390 |
| LAD-6-14-P-EZ | 6 | 60" | 90" | 34¼" x 62 3/8" | 14" | 210 |
| LAD-7-14-P-EZ | 7 | 70" | 100" | 34¼" x 70 7/8" | 14" | 235 |
| LAD-8-14-P-EZ | 8 | 80" | 110" | 34¼" x 85 5/16" | 14" | 257 |
| LAD-9-14-P-EZ | 9 | 90" | 120" | 34¼" x 91½" | 14" | 279 |
| LAD-10-14-P-EZ | 10 | 100" | 130" | 34¼" x 97 11/16" | 14" | 304 |
| LAD-11-14-P-EZ | 11 | 110" | 140" | 34¼" x 103 7/8" | 14" | 387 |
| LAD-6-21-P-EZ | 6 | 60" | 90" | 34¼" x 70 15/16" | 21" | 221 |
| LAD-7-21-P-EZ | 7 | 70" | 100" | 34¼" x 78 15/16" | 21" | 246 |
| LAD-8-21-P-EZ | 8 | 80" | 110" | 34¼" x 91 9/16" | 21" | 268 |
| LAD-9-21-P-EZ | 9 | 90" | 120" | 34¼" x 97¾" | 21" | 348 |
| LAD-10-21-P-EZ | 10 | 100" | 130" | 34¼" x 103 15/16" | 21" | 356 |
| LAD-11-21-P-EZ | 11 | 110" | 140" | 34¼" x 110 7/8" | 21" | 387 |
| LAD-GATE-58 | FOOT ACTIVATED SAFETY GATE 58° | 44 | ||||
| LAD-GATE-50-EZ | FOOT ACTIVATED SAFETY GATE 50° - EZ | 45 | ||||
| LAD-TT-B | TOOL TRAY | 14 |
| No. Of Steps | 6; 7; 8; 9; 10; 11 |
|---|---|
| Top Step Height | 60"; 70"; 80"; 90"; 100"; 110" |
| Top Step Depth | 14"; 21" |
Source: 2018 catalog, page 230. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Compare the documented dimensions, capacities and model options with the intended application. Include installation, access and operating requirements when requesting a quote.
The catalog lists LAD-6-14-G through LAD-TT-B within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include No. Of Steps: 6; 7; 8; 9; 10; 11; Top Step Height: 60"; 70"; 80"; 90"; 100"; 110". These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 230. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 51 model references for this family. The first listed model is LAD-6-14-G. Compare the model rows and confirm the required configuration when quoting.
Choose an access configuration around the required standing height, approach and available floor space. Check the model’s dimensions against the work area before selecting it.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
