| Model / reference | Width | Style | Shelf / qty | Bin Brackets / Back | Bin Brackets / Doors | Bins / Doors | Dimensions W x D x H (in) / Doors | Steel Gauge / Doors | Weight (lb) / Doors | Shelf / lb |
|---|---|---|---|---|---|---|---|---|---|---|
| F89126 | 36” | Base | - | Full | Full | - | 36 x 24 x 78 | 14 | 284 | — |
| F89125 | 36” | Shelf Only | 4 | - | Full | - | 36 x 24 x 78 | 14 | 318 | 1,000 |
| F89124 | 36” | Door Bins | 4 | - | Full | 96: (96) XS | 36 x 24 x 78 | 14 | 332 | 1,000 |
| F89123 | 36” | Half Bins | 3 | Half | Full | 102: (96) XS, (6) XL | 36 x 24 x 78 | 14 | 350 | 1,000 |
| F89122 | 36” | Full Bins | - | Full | Full | 138: (96) XS, (24) M, (12) L, (6) XL | 36 x 24 x 78 | 14 | 346 | 1,000 |
| F89109 | 48” | Base | - | Full | Full | - | 48 x 24 x 78 | 14 | 352 | 1,000 |
| F89121 | 48” | Shelf Only | 4 | - | Full | - | 48 x 24 x 78 | 14 | 392 | 1,000 |
| F87451A6 | 48” | Door Bins | 4 | - | Full | 120: (120) XS | 48 x 24 x 78 | 14 | 410 | 1,000 |
| F87842A4 | 48” | Half Bins | 3 | Half | Full | 126: (120) XS, (6) XL | 48 x 24 x 78 | 14 | 429 | 1,000 |
| F87843A3 | 48” | Full Bins | - | Full | Full | 147: (120) XS, (9) L, (18) XL | 48 x 24 x 78 | 14 | 431 | 1,000 |
| F89108 | 60” | Base | - | Full | Full | - | 60 x 24 x 84 | 14 | 471 | 1,000 |
| F89117 | 60” | Shelf Only | 4 | - | Full | - | 60 x 24 x 84 | 14 | 541 | 1,000 |
| F89116 | 60” | Door Bins | 4 | - | Full | 160: (160) XS | 60 x 24 x 84 | 14 | 566 | 1,000 |
| F87954A6 | 60” | Half Bins | 3 | Half | Full | 172: (160) XS, (12) XL | 60 x 24 x 84 | 14 | 594 | 1,000 |
| F87953A7 | 60” | Full Bins | - | Full | Full | 196: (160) XS, (24) L, (12) XL | 60 x 24 x 84 | 14 | 573 | 1,000 |
| F89107 | 72” | Base | - | Full | Full | - | 72 x 24 x 84 | 14 | 551 | 1,000 |
| F89113 | 72” | Shelf Only | 4 | - | Full | - | 72 x 24 x 84 | 14 | 629 | 1,000 |
| F89112 | 72” | Door Bins | 4 | - | Full | 192: (192) XS | 72 x 24 x 84 | 14 | 657 | 1,000 |
| F85869A6 | 72” | Half Bins | 3 | Half | Full | 204: (192) XS, (12) XL | 72 x 24 x 84 | 14 | 687 | 1,000 |
| F89110 | 72” | Full Bins | - | Full | Full | 276: (192) XS, (48) M, (24) L, (12) XL | 72 x 24 x 84 | 14 | 676 | 1,000 |
| Documented model configurations | 20 |
|---|---|
| Bin Brackets / Doors | Full |
| Steel Gauge / Doors | 14 |
| Catalog feature / option | Shelves are easily adjustable on 7 3/8” increments, 1,000 lb. capacity per shelf. |
Source: 2025 storage and handling catalog, PDF page 4. Confirm the current selected configuration with your quote.
PRODUCT INFORMATION
Bin and Shelf Storage Cabinets is presented here with the configurations documented in the 2025 storage and handling catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.
Catalog features and options: Protect, store, and easily find your tools, parts, and supplies.; Heavy duty 14 gauge steel construction, fully welded.; Variety of bin and shelf configurations to fit your needs.; Louvered bin brackets for hanging plastic storage bins.; 18” Deep shelves allow bins on doors to be unobstructed when closed.; Shelves are easily adjustable on 7 3/8” increments, 1,000 lb. capacity per shelf.; Full piano hinge doors improve stability and durability.; Zinc plated handle with 3-point locking system helps keep items secure, key included.; 60” & 72” Width models include 6” raised legs for improved stability and durability.; Additional accessories sold separately.; Premium powder coat paint finish.; Ships fully assembled, ready to use..
Model and option notes: F89109*; F89121* Shelf Only 4; F87451A6* Door Bins 4 120: (120) XS 410; F87842A4* Half Bins 3 Half 126: (120) XS, (6) XL 429; F87843A3* Full Bins - Full 147: (120) XS, (9) L, (18) XL 431; • Additional accessories sold separately..
Reference: 2025 storage and handling catalog, PDF page 4. The tables reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.
These specifications come from the 2025 storage and handling catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.
Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.
