Deep-Door Bin and Shelf Storage Cabinets — catalog equipment photograph

Open an image to inspect its original detail.

Specifications & options

Model / reference	Size W x H (in)	Style	Shelf / qty	Door Shelf / qty	Bin Brackets / Back	Bin Brackets / Doors	Bins / Doors	Dimensions W x D x H (in) / Doors	Steel Gauge / Doors	Weight (lb) / Doors	Shelf / lb	Door Shelf / lb
F89106	36 x 78	Base	-	-	Full	Full	-	36 x 24 x 78	14	309	—	—
F89105	36 x 78	Shelf Only	4	6	-	Half	-	36 x 24 x 78	14	339	1,000	100
F89104	36 x 78	Door Bins	4	6	-	Half	48: (48) XS	36 x 24 x 78	14	346	1,000	100
F89103	36 x 78	Half Bins	3	6	Half	Half	54: (48) XS, (6) XL	36 x 24 x 78	14	364	1,000	100
F89102	36 x 78	Full Bins	-	-	Full	Full	138: (96) XS, (24) M, (12) L, (6) XL	36 x 24 x 78	14	371	1,000	100
F89101	48 x 78	Base	-	-	Full	Full	-	48 x 24 x 78	14	378	1,000	100
F89100	48 x 78	Shelf Only	4	6	-	Half	-	48 x 24 x 78	14	410	1,000	100
F89099	48 x 78	Door Bins	4	6	-	Half	72: (72) XS	48 x 24 x 78	14	421	1,000	100
F89098	48 x 78	Half Bins	3	6	Half	Half	78: (72) XS, (6) XL	48 x 24 x 78	14	440	1,000	100
F89097	48 x 78	Full Bins	-	-	Full	Full	147: (120) XS, (9) L, (18) XL	48 x 24 x 78	14	457	1,000	100
F89096	48 x 84	Base	-	-	Full	Full	-	48 x 24 x 84	14	397	1,000	100
F87972A8	48 x 84	Shelf Only	4	6	-	Half	-	48 x 24 x 84	14	429	1,000	100
F89094	48 x 84	Door Bins	4	6	-	Half	72: (72) XS	48 x 24 x 84	14	440	1,000	100
F87971A9	48 x 84	Half Bins	3	6	Half	Half	78: (72) XS, (6) XL	48 x 24 x 84	14	459	1,000	100
F87969A1	48 x 84	Full Bins	-	-	Full	Full	163: (136) XS, (9) L, (18) XL	48 x 24 x 84	14	480	1,000	100

Documented model configurations	15
Steel Gauge / Doors	14
Catalog feature / option	1,000 lb. capacity per interior shelf, 100 lb. capacity per door shelf.

Source: 2025 storage and handling catalog, PDF page 5. Confirm the current selected configuration with your quote.

PRODUCT INFORMATION

Equipment overview

Deep-Door Bin and Shelf Storage Cabinets is presented here with the configurations documented in the 2025 storage and handling catalog. Use the comparison table to select the required capacity, dimensions and operating arrangement.

Catalog features and options: 4” Deep door design provides added storage, organization, and durability.; Keep items organized, clean, and secure.; Protect, store, and easily find your tools, parts, and supplies.; Heavy duty 14 gauge steel construction, fully welded.; Variety of bin and shelf configurations to fit your needs.; Louvered bin brackets for hanging plastic storage bins.; 18” Deep interior shelves are easily adjustable on 7 3/8” increments.; 4” Deep door shelves are easily adjustable on 4” increments.; 1,000 lb. capacity per interior shelf, 100 lb. capacity per door shelf.; Zinc plated handle with 3-point locking system helps keep items secure, key included.; Additional accessories sold separately.; Premium powder coat paint finish.; Ships fully assembled, ready to use..

Model and option notes: • Additional accessories sold separately..

Documentation & drawings

Reference: 2025 storage and handling catalog, PDF page 5. The tables reproduce the documented configurations.

Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.

Request model documentation ↗

Questions about this equipment

How do I choose a model or configuration?

Compare the documented model dimensions and capacities with your application. Include the selected reference, quantity, required load, power supply and site constraints with your request.

Are the catalog specifications current?

These specifications come from the 2025 storage and handling catalog. Ask for current model-specific drawings, installation requirements and any required compliance documents before ordering.

How do I request a quote?

Choose a listed configuration or request selection help. Include quantity, application, delivery destination, unloading restrictions and your needed-by date.

Industrial Storage Cabinets

Deep-Door Bin and Shelf Storage Cabinets

Manufacturer: Valley Craft

Deep-Door Bin and Shelf Storage Cabinets. Documented model configurations: 15. Steel Gauge / Doors: 14. Catalog feature / option: 1,000 lb. capacity per interior shelf, 100 lb. capacity per door shelf..

Find a model in this family Model for your quote

Select a reference to review its listed specifications. Tables may also include accessories and optional configurations.

Request a configuration quote

Documented model configurations: 15
Steel Gauge / Doors: 14
Catalog feature / option: 1,000 lb. capacity per interior shelf, 100 lb. capacity per door shelf.

Review quote request →

Confirm configuration, quantity, freight and needed-by date with your request.

Questions about the application? (866) 410-7852

Prepare your technical requirements

Include quantity, application, required dimensions and load, power supply, site constraints, delivery address and timing.

For a custom configuration, have drawings or specifications ready. Our team can confirm the file-delivery method with your quote request.
