| MODEL NUMBER | ALUMINUM YARD RAMPS WITH ALUMINUM GRATING UNIFORM CAPACITY | OVERALL** RAMP WIDTH | USABLE RAMP WIDTH | LENGTH (FEET) | WEIGHT (POUND) |
|---|---|---|---|---|---|
| AY-168430 | 16,000 lb. | 86" | 78" | 30 | 3150 |
| AY-169330 | 16,000 lb. | 95" | 87" | 30 | 3465 |
| AY-167236-L | 16,000 lb. | 74" | 66" | 36 | 3360 |
| AY-168436-L | 16,000 lb. | 86" | 78" | 36 | 3728 |
| AY-169336-L | 16,000 lb. | 95" | 87" | 36 | 3990 |
| AY-207230 | 20,000 lb. | 74" | 66" | 30 | 2888 |
| AY-208430 | 20,000 lb. | 86" | 78" | 30 | 3255 |
| AY-209330 | 20,000 lb. | 95" | 87" | 30 | 3570 |
| AY-207236-L | 20,000 lb. | 74" | 66" | 36 | 3465 |
| AY-208436-L | 20,000 lb. | 86" | 78" | 36 | 3833 |
| AY-209336-L | 20,000 lb. | 95" | 87" | 36 | 4095 |
| AY-257230 | 25,000 lb. | 74" | 66" | 30 | 2940 |
| AY-258430 | 25,000 lb. | 86" | 78" | 30 | 3308 |
| AY-259330 | 25,000 lb. | 95" | 87" | 30 | 3675 |
| AY-257236-L | 25,000 lb. | 74" | 66" | 36 | 3578 |
| AY-258436-L | 25,000 lb. | 86" | 78" | 36 | 3885 |
| AY-259336-L | 25,000 lb. | 95" | 87" | 36 | 4200 |
| AY-307230 | 30,000 lb. | 74" | 66" | 30 | 3092 |
| AY-308430 | 30,000 lb. | 86" | 78" | 30 | 3360 |
| AY-307236-L | 30,000 lb. | 74" | 66" | 36 | 3570 |
| AY-308436-L | 30,000 lb. | 86" | 78" | 36 | 3938 |
| MODEL NUMBER | ALUMINUM YARD RAMPS WITH STEEL GRATING | UNIFORM CAPACITY | OVERALL WIDTH | USABLE WIDTH | LENGTH (FEET) | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| SY-167230 | 16,000 lb. | 74" | 66" | 30 | 3518 | |
| SY-168430 | 16,000 lb. | 86" | 78" | 30 | 4043 | |
| SY-169330 | 16,000 lb. | 95" | 87" | 30 | 4515 | |
| SY-167236-L | 16,000 lb. | 74" | 66" | 36 | 4305 | |
| SY-168436-L | 16,000 lb. | 86" | 78" | 36 | 4830 | |
| SY-169336-L | 16,000 lb. | 95" | 87" | 36 | 5303 | |
| SY-207230 | 20,000 lb. | 74" | 66" | 30 | 3623 | |
| SY-208430 | 20,000 lb. | 86" | 78" | 30 | 4148 | |
| SY-209330 | 20,000 lb. | 95" | 87" | 30 | 4620 | |
| SY-207236-L | 20,000 lb. | 74" | 66" | 36 | 4410 | |
| SY-208436-L | 20,000 lb. | 86" | 78" | 36 | 4935 | |
| SY-209336-L | 20,000 lb. | 95" | 87" | 36 | 5408 | |
| SY-257230 | 25,000 lb. | 74" | 66" | 30 | 3675 | |
| SY-258430 | 25,000 lb. | 86" | 78" | 30 | 4200 | |
| SY-259330 | 25,000 lb. | 95" | 87" | 30 | 4725 | |
| SY-257236-L | 25,000 lb. | 74" | 66" | 36 | 4463 | |
| SY-258436-L | 25,000 lb. | 86" | 78" | 36 | 4988 | |
| SY-259336-L | 25,000 lb. | 95" | 87" | 36 | 5513 | |
| SY-307230 | 30,000 lb. | 74" | 66" | 30 | 3728 | |
| SY-308430 | 30,000 lb. | 86" | 78" | 30 | 4253 | |
| SY-307236-L | 30,000 lb. | 74" | 66" | 36 | 4515 | |
| SY-308436-L | 30,000 lb. | 86" | 78" | 36 | 5040 |
| Aluminum Yard Ramps With Aluminum Grating Uniform Capacity | 16,000 lb.; 20,000 lb.; 25,000 lb.; 30,000 lb. |
|---|---|
| Overall** Ramp Width | 86"; 95"; 74" |
| Usable Ramp Width | 78"; 87"; 66" |
| Length (Feet) | 30; 36 |
| Uniform Capacity | 16,000 lb.; 20,000 lb.; 25,000 lb.; 30,000 lb. |
| Overall Width | 74"; 86"; 95" |
Source: 2018 catalog, page 21. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Plan the transfer path between a loading area and the vehicle or receiving surface. Match the model to the height difference, usable width and intended loading method.
The catalog lists AY-168430 through SY-308436-L within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Aluminum Yard Ramps With Aluminum Grating Uniform Capacity: 16,000 lb.; 20,000 lb.; 25,000 lb.; 30,000 lb.; Overall** Ramp Width: 86"; 95"; 74". These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 21. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 43 model references for this family. The first listed model is AY-168430. Compare the model rows and confirm the required configuration when quoting.
Plan the transfer path between a loading area and the vehicle or receiving surface. Match the model to the height difference, usable width and intended loading method.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
