| MODEL NUMBER | DESCRIPTION | UNIFORM CAPACITY | WEIGHT (POUND) |
|---|---|---|---|
| RU-600-SCB | 6'W x 6'L Recessed Unit, Standard 28" Deep Pit | 20,000 lb. | 2056 |
| RU-800-SCB | 6'W x 8'L Recessed Unit | 20,000 lb. | 2425 |
| RU-800-SCB-F | 6'W x 8'6"L Recessed Unit | 20,000 lb. | 2475 |
| RU-1000-SCB | 6'W x 10'L Recessed Unit | 20,000 lb. | 2730 |
| SU-600-SCB | 6'W x 6'L Recessed Unit with Legs, Full 48" Deep Pit | 20,000 lb. | 2147 |
| SU-800-SCB | 6'W x 8'L Recessed Unit with Legs | 20,000 lb. | 2516 |
| SU-800-SCB-F | 6'W x 8'6"L Recessed Unit with Legs | 20,000 lb. | 2592 |
| SU-1000-SCB | 6'W x 10'L Recessed Unit with Legs | 20,000 lb. | 2821 |
| PU-600-SCB | (Dock Leveler Unit with Legs for in Front of Dock Placement) | 20,000 lb. | 2394 |
| PU-800-SCB | (Dock Leveler Unit with Legs for in Front of Dock Placement) | 20,000 lb. | 2830 |
| PU-1000-SCB | (Dock Leveler Unit with Legs for in Front of Dock Placement) (SPECIFY DOCK HEIGHT WHEN ORDERING) | 20,000 lb. | 3203 |
| MODEL NUMBER | TRUCK ACTUATED DOCK LEVELER OPTIONS | DESCRIPTION | WEIGHT (POUND) |
|---|---|---|---|
| WS-DV | DUAL VINYL WEATHER STRIPPING (FACTORY INSTALLED) | -- | |
| CAS-RU-600 | CURB ANGLE SET | FOR SERIES RU-600 DOCK LEVELER | 196 |
| CAS-RU-800 | CURB ANGLE SET | FOR SERIES RU-800 DOCK LEVELER | 214 |
| CAS-RU-800-F | CURB ANGLE SET | FOR SERIES RU-800-F DOCK LEVELER | 318 |
| CAS-RU-1000 | CURB ANGLE SET | FOR SERIES RU-1000 DOCK LEVELER | 233 |
| TA-30K/6 | 30,000 POUND CAPACITY | FOR 6 FOOT LENGTH | -- |
| TA-30K/8 | 30,000 POUND CAPACITY | FOR 8 FOOT LENGTH | -- |
| TA-30K/10 | 30,000 POUND CAPACITY | FOR 10 FOOT LENGTH | -- |
| FI | FOAM INSULATION | 6 | |
| TL | NOTCH FOR TRAILER LOCK | -- | |
| SPO | SHALLOW PIT OPTION FOR SERIES | -- | |
| SPO-RU | SHALLOW PIT OPTION FOR SERIES RU (minimum depth 24") | -- | |
| BE | BUMPER EXTENSION FOR LOW DOCKS | -- |
| Uniform Capacity | 20,000 lb. |
|---|---|
| Truck Actuated Dock Leveler Options | CURB ANGLE SET; 30,000 POUND CAPACITY; FOAM INSULATION; NOTCH FOR TRAILER LOCK |
Source: 2018 catalog, page 9. Confirm current specifications and options for the selected model.
PRODUCT INFORMATION
Plan the transfer path between a loading area and the vehicle or receiving surface. Match the model to the height difference, usable width and intended loading method.
The catalog lists RU-600-SCB through BE within this family. Use the comparison tables below to check the documented specifications for each reference. Accessories and optional configurations are identified separately where the source provides them.
Configuration details in this range include Uniform Capacity: 20,000 lb.; Truck Actuated Dock Leveler Options: CURB ANGLE SET; 30,000 POUND CAPACITY; FOAM INSULATION; NOTCH FOR TRAILER LOCK. These values cover multiple models; consult the individual row for the model being quoted.
These specifications come from the 2018 catalog. Current design, options and availability must be confirmed with your quote. Include the model reference, quantity, application, delivery address and required timing.
Reference: 2018 product catalog, page 9. The model tables above reproduce the documented configurations.
Request the current model-specific manual, dimensional drawings and installation requirements for your application. Confirm any required compliance documentation with the quote.
Request model documentation ↗The catalog records 24 model references for this family. The first listed model is RU-600-SCB. Compare the model rows and confirm the required configuration when quoting.
Plan the transfer path between a loading area and the vehicle or receiving surface. Match the model to the height difference, usable width and intended loading method.
The comparison tables reflect the 2018 catalog. Current specifications, options and availability require confirmation for the selected model.
